PARTNER ASHOK LEYLAND PICK UP CHASSIS PAYLOAD 4.5 APPROX TON MY23 Light Duty Diesel

Specs: Code

Year: 2023

Model description

Model description:

PARTNER ASHOK LEYLAND PICK UP CHASSIS PAYLOAD 4.5 APPROX TON MY23 Light Duty Code Diesel

Car code:

APC4523 - 4.5 Ton approx (chassis)

Year:

2023

Engine & Transmission

Engine:

ZD30 E3 diesel engine with DDTI ( Double Overhead Camshaft, Common Rail, Direct Injection, Turbo intercolled)

Max Output :

118 HP @ 2750 RM (BS3)

Max Torque :

320 Nm @ 1350 - 2600 RPM (BS3)

Transmission:

Fully synchromesh 5 forward & 1 Reverse

Dimension, Capacities & Suspensions

Gross Vehicle Weight:

7200 kg

Payload:

4.5 Ton approx

Shipping Dimension:

6946 x 1961 x 2100 mm

Shipping Weight:

2300 kg

Chassis Length:

4230 mm

Chassis Width:

2060 mm

Displacement / Cubic Capacity:

2953 cc

Clutch:

280 mm Dia, single dry plate, Diaphragm push type

Fuel Tank Capacity:

90 Liters

Front Suspension:

Parabolic with double acting shock absorbers

Rear Suspension:

Semi elliptic with double acting shock absorbers

No. of Tyres:

Front 2, Rear 4, Spare 1

Tyre Size:

7.50 x 16-16 PR

Turning Circle Radius:

6.75 m

Min. Ground Clearance:

220 mm

Wheelbase:

3320 mm

Battery:

1x75 AH

Alternator:

90 (A)

Steering System:

Power steering

Service Brake:

Dual circuit hydraulic with vacuum assist and LCRV

Parking Brake:

Transmission mounted, cable operated

Gradeability:

23%

Max Speed:

95 km/hr

Interior features & Safety

Tiltable power steering

Reclining & Sliding driver seats

Door handle cum armrest (Driver & Co-driver

Digital clock ( on instrument cluster)

Mobile charging point (12V)

Lockable glove box

Windshield defogger

3 point type ELR seat belt

Fog lamp provision

Vacuum assisted brakes with LCRV

Titable cabin

Cable type gear shift

Low vacuum in brake booster indicator

Speed Limiting on ECU

Provision for power take off (mechanical)

Specifications may change without prior notice.
